uxcell 5pcs ZP4510 Liquid Water Level Sensor Vertical Float Switches

Specifications:
Product Name: Float Switch
Max Contact: Rating 10W
Max Switching Voltage: 100V DC
Max Switching Current: 0.5A
Max Breakdown Voltage: 220V DC
Max Carry Current: 1.0A
Max Contact Resistance: 100mohm
Temperature Rating: -10 ~ +60 C / 85 C
Float Ball Material: PPFloat
Body Material: PP
Float Ball Size(Approx): 22 x 24mm(L*D)
Thread Dia(Approx): M9mm
Body Total Length: 45mm
Cable Length: 37cm
Color: White
Net Weight: 8g
Package Content
5 x Float Switch
Description:
1.A float switch is a device used to sense the level of liquid within a tank.
2.The switch may actuate a pump, an indicator, an alarm, or other device.
3.It can be easily converted from normally open to normally close by inverting the float.
4.Note: because the current that the switch can carry is much little(0.5A), you must use a relay or contactor when it is connected by a load, relay and contactor are not included here.
Feature:
1.This float switch is a simple structure,easy installation liquid level controller.
2.It does not have a complex circuit,will not be disturbed,as long as the material selection,liquid,pressure or temperture can be used in any environment.
