Zebra ZT23042-D01100FZ Direct Thermal Printer 203 DPI, Monochrome, With Parallel Connection
The Zebra ZT230 Industrial Direct Thermal Tabletop Label Printer with metal frame, parallel connection, and larger ribbon capacity than the Zebra ZT220 prints 4" wide labels at 6" per second and 203 dpi (8 dots/mm). An element energy equalizer (E3) and side-loading metal print mechanism with head open lock help to increase work efficiency. It has an LCD graphical user interface for reading and navigation and 128 MB Flash and 128 MB RAM for high throughput. Media sensors are transmissive and reflective to accommodate different label types including continuous, die-cut, notch, and black mark. Additional connection options include serial and USB 2.0.
Specifications | |
---|---|
Dimensions* | 10.9 x 9.5 x 17 inches/277 x 242 x 432 mm (H x W x D) |
Print width x length | Width: 4.09"/104 mm width, Length: 157"/3,988 mm |
Print speed | 6"/152 mm per second |
Label and liner width | Minimum: 0.75"/19.4 mm, Maximum: 4.50"/114 mm |
Maximum non-continuous label length | 39"/991 mm |
Maximum Media Roll Size | 8.0"/203 mm OD on a 3"/76 mm ID core, 6.0"/152 mm OD on a 1"/25 mm ID core |
Media thickness | 0.003"/0.076 mm to 0.010"/0.25 mm |
Ribbon outside diameter | 300 m: 2.7"/68.6 mm; 450 m: 3.2"/81.3 mm
 |
Standard ribbon length | 984'/300 m or 1476'/450 m |
Ribbon width | 1.57"/40 mm to 4.33"/110 mm |
ID Core | 1.0"/25.4 mm |
Agency approvals | IEC 60950, EN 55022 Class B, EN55024, EN 61000-3-2, EN 61000-3-3 |
*H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back.
Thermal printers can be used to print receipts, labels, tags, and other similarly sized media at point of sale (POS) locations. Direct thermal printers and thermal transfer printers use heat instead of ink to print on coated thermal media. A parallel, serial, or USB port allows a receipt printer to be connected to a computer. An Ethernet port or wireless capabilities may enable it to be connected to a computer network. Thermal printers can be used at retail checkout counters and other points of sale.
Zebra Technologies manufactures barcode, receipt, kiosk, and radio-frequency identification (RFID) printers and accessories. The company, founded in 1969, is headquartered in Lincolnshire, IL.
