YG-1 E5981 Carbide Square Nose End Mill, Long Reach, Uncoated (Bright) Finish, Finishing Cut, Non-Center Cutting, 45 Deg Helix, 3 Flutes, 2.5" Overall Length, 0.3125" Cutting Diameter, 0.3125" Shank Diameter

The YG-1 E5981 uncoated carbide square nose end mill has a 45-degree helix, three flutes, and a center-cutting design for high-performance machining of aluminum and other nonferrous materials. The end mill's geometry allows for high cutting speeds, smooth cutting action, and stability. The 45-degree helix angle offers increased cutting action compared to end mills with lower helix angles, as it moves excess material quickly up the spiral and away from the workpiece. It has three flutes to provide better chip-carrying capacity than four flutes and a finer finish than two. They efficiently remove excess material from the cutting area and provide a third cutting edge to create an improved finish that may eliminate the need for a second finishing cut in some applications. The tool€s square end creates sharp, unrounded cuts. The center-cutting design has cutting teeth at the end of the tool, so it can be fed into the workpiece like a drill bit.

Carbide is harder than high-speed or cobalt steel, making it more wear resistant at high speeds and providing longer tool life. This tool has no coating or surface treatment. Cutting diameter tolerance is + 0.0000 to - 0.0005". The round shank accommodates a range of tool holders.

End mills are designed to remove material and create multi-dimensional shapes and profiles. They have cutting edges along the outside diameter and flutes that remove chips from the cutting area and allow cooling fluids to enter. If heat is not reduced effectively, the tool€s cutting edges will dull and additional material buildup can occur. The number of flutes can range from two to eight. Two-flute designs offer the most efficient chip removal, but more flutes provide a smoother finish. The shank is the end of the tool held in place by a tool holder or machine. Center-cutting end mills can create three-dimensional shapes and profiles, and make plunge cuts similar to a drill bit. Non-center-cutting end mills are for applications such as peripheral milling and finishing, but cannot make plunge cuts.

YG-1 manufactures drills, taps, end mills, and rotary tooling. The company, founded in 1981, is headquartered in South Korea and has a U.S. office in Vernon Hills, IL.

  • TitleYG-1 E5981 Carbide Square Nose End Mill, Long Reach, Uncoated (Bright) Finish, Finishing Cut, Non-Center Cutting, 45 Deg Helix, 3 Flutes, 2.5" Overall Length, 0.3125" Cutting Diameter, 0.3125" Shank Diameter
  • BrandYG-1
  • ManufacturerYG-1 Tool Company
  • BindingMisc.
  • ProductGroupBISS
  • ItemPartNumber28579
  • Model28579
  • Size5/16 inches
  • UnitCount1
  • UPCs380610530785
  • EANs0380610530785
