Xprotolab Plain- Plug-in breadboard Oscilloscope, Waveform generator and Protocol sniffer

Xprotolab Plain Plug-in Mixed Signal Oscilloscope


The Xprotolab Plain is the most inexpensive but feature rich oscilloscope in the market. It consists of a simple DIP module with a USB interface. Visualization of the signals and controlling the oscilloscope is done on the PC interface software (open source). The Xprotolab Plain is similar to the original Xprotolab, but doesn't have the display and buttons, so it only works with the USB interface. The board measures only 1 x 2 inches, and can be mounted directly on a breadboard. The Xprotolab can also be used as a development board for the AVR XMEGA microcontroller.



Features:

  • Mixed Signal Oscilloscope: Simultaneous sampling of analog and digital signals
  • Advanced Trigger: Normal / Single / Auto, with rising or falling edge and adjustable trigger level
  • Meter Mode: Average, Peak to peak and Frequency readout
  • XY Mode:
               Plot Lissajous patterns
               See the phase difference between two waveforms
               V/I Curve tracer with an external resistor
  • Spectrum Analyzer with different windowing options and selectable vertical log
  • Horizontal and Vertical Cursors with automatic waveform measurements
  • Arbitrary Waveform Generator with Sweep on all parameters
  • Display options: Persistence, Different grid options, and more
  • Curve tracer function
  • Includes: Two 10-pin headers

    Specifications:

    General Specifications:

      ATXMEGA32A4U 36KB Flash, 4KB SRAM, 1KB EEPROM
      Module size: 1.98" x 1.01"
      PDI interface
      USB connectivity: Windows, Linux, Mac, Android

    Logic Analyzer specifications:

      8 Digital Inputs, 3.3V level
      Maximum sampling rate: 2MSPS
      Frequency counter: 16MHz
      Protocol Sniffer: UART, I2C, SPI

      • TitleXprotolab Plain- Plug-in breadboard Oscilloscope, Waveform generator and Protocol sniffer
      • BrandGABOTRONICS
      • ManufacturerGabotronics
      • ProductGroupBISS
      • ItemPartNumberGT-0007
      • UnitCount1
