Top-cofrLD Hdmi to Hdmi + Audio Decoder Extractor Splitter - Hdmi to Spdif Digital Optical/Analog 5.1 - Support Dolby Digital Ac3,DTS,lpcm
The HDMI TO HDMI Audio Decoder allows you to extract audio signals from your HDMI source. You can take your original HDMI audio signal and convert it to digital optical or analog 5.1 sound track output. This product supports Dolby digital AC-3, DTS, LPCM and other digital audio format decoding. It is one perfect audio decoder for your DVD, Blue-Ray DVD, PS3, X360BOX, HD Player, PC etc.
Specification: Â Â
               HDMI resolution: up to 1080P/50/60fs (3D 24/30fs)
Support video color format:Â 24bit/deep color 30bit,36bit
HDMI Audio Format:Â DTS-HD/Dolby-TrueHD/LPCM 2/5.1/7.1CH/DTS/Dolby-AC3/DSD
Digital audio decode format:Â Dolby Digital (AC3)/DTS/LPCM 2CH
HDMI Max bandwidth:Â 225MHz
HDMI Max baud rate:Â 6.75Gbps
Input/Output TMDS signal:Â 0.5~1.5Volts p-p(TTL)
Input/Output DDC signal:Â 5Volts p-p (TTL)
DSP sample frequency range:Â 32~96 KHz
DSP Bit rate range:Â 16~24 Bit
Analog output level(1kHz@0dB):Â 1V RMS
SNR @ 0dB(CCIR/ARM): ‰¥85dB
Distortion: ‰¤0.1%
Frequency response:Â 20Hz~20KHz
Headphone output power (1kHz@0dB RL=32):Â 20mW
HDMI input cable distance: ‰¤15m AWG26 HDMI standard cable
HDMI output cable distance: ‰¤18m AWG26 HDMI standard cable
Max working current :Â 500mA
Power adapter format Input:Â AC 100V~240V 50HZ/60Hz, DC5V/1A
Package Includes:
1 x HDMI TO HDMI + Audio Decoder
1 x AC power adapter
1 x User manualÂ
