Tarot 2 axis Gyroscope ZYX22 Gyro for TL68A08 T-2D Brushless Gimbal Gopro 3 FPV

Product Information:
Tarot 2 axis Gyroscope ZYX22 Gyro for TL68A08 T-2D Brushless Gimbal Gopro 3 FPV Aerial Photography
Software and manual can be downloaded at kingwjg.com/ZYX/Gopro.rar

Descriptions:
Suitable for GOPRO brushless yuntai TL68A08 (SKU:25824) brushless gimbal or other similar products, used in entertainment, film and television photography, advertising model aircraft photography and so on many fields.

Features:
1.Operating voltage: 7.4 V ~ 14.8 V DC (recommended 12 V, three lithium electricity
2.Work current :200 ma - 500 ma (related to the power supply voltage and motor power
3.Working environment temperature: 15-65C
4.Processor: dual high-speed 32-bit ARM core processor
5.Sensors: three MEMS gyroscope rotor and rotor MEMS accelerometer
6.Maximum angular rate: 2000 deg/ SEC
7.Maximum acceleration: 16 g
8.Control frequency: 2000 hz
9.Motor drive frequency: 20 KHZ (noiseless smooth drive)
10.Accuracy:0.1 deg
11.Control range: - 45 ~ 45 (roll), - 135 ~ 90 (pitch)
12.Gesture decoding algorithm: dedicated to brushless motor driven yuntai decoupling EKF algorithm
13.Applicable filming equipment: GOPRO Hero3

Package Including:
ZYX3 rotor gyroscope quad ZYX07 x 1
GOPRO two axis gyro sensor x1
GOPRO gimbal two axis gyroscope main controllerx 1
4.5x 4.5 MM insulation spacer x 4
2x3 mm round head cross screw x8

NOTE:
Brushless gimbal is very sensitive to vibrations. So if your copter props, engines, frame are not balanced or you copter is flexible, it will cause bad reactions of gimbal in flight.
