TP-Link 5GHz N300 Long Range Outdoor CPE for PtP and PtMP Transmission | Point to Point Wireless Bridge | 13dBi, 15km+ | Passive PoE Powered w/ Free PoE Injector | Pharos Control (CPE510) White
TP-LINK's 5GHz 300Mbps 13dBi Outdoor CPE, the CPE510 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application, it is ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications. Â Professional performance, coupled with user-friendly design, makes CPE510 an ideal choice for both business and home users.
Maximum wireless transmission rates are the physical rates derived from IEEE Standard 802.11 specifications. Range and coverage specifications along with the number of connected devices were defined according to test results under normal usage conditions. Actual wireless transmission rate, wireless coverage, and number of connected devices are not guaranteed, and will vary as a result of 1) environmental factors, including building materials, physical objects and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead and 3) client limitations, including rated performance, location, connection quality, and client condition.
Protection against lightning and electro-static discharge may be achieved through proper product setup, grounding and cable shielding. Refer to the instruction manual and consult an IT professional to assist with setting up this product.
Power supply distances are based on test results under normal usage conditions. Actual power supply distance will vary as a result of 1) AP status, including transmit power, connected devices and network traffic along with 2) cable properties, including type and texture, and 3) environmental factors, which include temperature and humidity. Frequency Range: 5.15~5.85GHz. Note: Available operating frequency may vary depending on the limitations of the countries or regions in which the device is used.; Interface Available: 1 x 10/100Mbps Shielded Ethernet Port (Passive PoE in), 1 Grounding Terminal, 1 Reset Button, 1 AC Jack with Earth Ground, 1 10/100/1000Mbps Shielded Ethernet Port (Power + Data); Processor: Qualcomm Atheros Enterprise 560MHz CPU MIPS 74Kc; Internal Memory: 64MB DDR2 RAM 8MB Flash; Protocols Supported: TDMA Mode (with Pharos MAXtream enabled); System Requirement: Microsoft Windows 98SE NT 2000 XP Vista, or Windows 10 Windows 8 Windows 7 MAC OS NetWare UNIX or Linux., Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome Safari and Firefox. IE browsers are not recommended.; Wireless Standards: IEEE 802.11a/n (with Pharos MAXtream disabled)
