Supermicro 10 Bulk, Dual Intel 64-BIT Xeon Support (667/1066/1333MHZ Fsb), 32GB DDR2 667 &

Item #: K05302. This is a Special Order Item. Please allow up to 7 business days for product to ship. Built upon the functionality and the capability of the 5000X (Greencreek) chipset, the X7DAE motherboard provides the performance and feature set required for dual processor-based servers with configuration options optimized for communications, presentation, storage, computation or database applications. The 5000X (Greencreek) chipset supports single or dual Xeon 64-bit dual core processor with front side bus speeds of up to 1.333 GHz. The chipset consists of the 5000X (Greencreek) Memory Controller Hub (MCH), the Enterprise South Bridge 2 (ESB2), and the I/O subsystem (PXH-V).The 5000X (Greencreek) MCH chipset is designed for symmetric multiprocessing across two independent front side bus interfaces. Each front side bus uses a 64-bit wide, 1.333 GHz data bus that transfers data at 10.7 GB/sec. (for a total bandwidth of 21.3 GB/sec.) The MCH chipset connects up to 8 Fully Buffered DIMM modules, providing a total of 32.0 GB/s for DDR2 667/533 memory. The MCH chipset also provides three x8 PCI-Express and one x4 ESI interface to the ESB2. In addition, the 5000X (Greencreek) chipset offers a wide range of RAS features, including memory interface ECC, x4/x8 Single Device Data Correction, CRC, parity protection, memory mirroring and memory sparing. Product Description: SUPERMICRO X7DAE - motherboard - extended ATX - 5000X
Product Type: Motherboard
Form Factor: Extended ATX
Dimensions (WxDxH): 12 in x 13.1 in
Chipset Type: Intel 5000X
Max Bus Speed: 1333 MHz
Processor: 0 ( 2 ) - LGA771 Socket
Compatible Processors: Dual-Core Xeon
64-bit Processors Compatibility: Yes
RAM: 0 MB (installed) / 32 GB (max)
Supported RAM Technology: DDR2 SDRAM
Supported RAM Integrity Check: ECC
Storage Controller: ATA-100, Serial ATA-300 (RAID)
USB Ports Configuration: 6 x USB
Storage Ports Configuration: 1 x ATA, 6 x SATA
Audio Output: Sound card
