Spray Gun Kit Gravity Feed 3 Sprayers HVLP
Features:
Stainless steel nozzle and needle to allow use aqueous based paint for long time
Precise 1.8mm,1.4mm & 1.0mm stainless steel needle and nozzle set.
3 Knobs for full adjustment: fluid, pattern and air pressure controls.
Two 1000ml and one 100ml aluminum cups with lids
A aluminum carrying case w/ locks for easily taking with
Comes with a air regulator with gauge
CE, GS certification
Applicants:
1.8mm set-up is ideal for the atomization of primers, sealers, thinned latex/oil base, and other medium to heavy viscosity coatings.
This 1.4mm set-up for spraying basecoats, clearcoats, single stage and other light to medium viscosity coatings.
1.0mm spray gun used for tight areas, small jobs and touch up
Specifications:
Spray Gun Full Size Spray Guns Mini Size Spray Gun
Nozzle Size 1.8 mm 1.4 mm 1.0 mm
Air Inlet 1/4"
Type of Feed Gravity
Recommended Air Pressure 0-43 psi (0-2.9 bar) 0-30 psi (0-2 bar)
Max. Pressure of Air 43 psi (2.9 bar) 30 psi (2 bar)
Paint Capacity 1000 ml 100 ml
Average Air Consumption 5-10 cfm 1-4 cfm
Pattern Width 6.3"-9.4" (160-240mm) 3.1"-3.9" (80-100 mm)
Operating Pressure 87 - 116 psi
Package Content:
1.8mm HVLP primer spray gun
1.4mm HVLP topcoat spray gun
1.0mm HVLP touch-up spray gun
2 1000ml aluminum cups w/ lids
100ml aluminum cup w/ lid
Locking air pressure regulator w/ gauge
Aluminum carrying box
Instruction manual
