SkyeTek Gemini NFC Reader Module Development Kit

The SkyeModule Gemini Evaluation Kit is a simple technology kit to support the SkyeModule Gemini. The Gemini is a low-cost, ultra-low power, MIFARE and NFC reader/writer module. A cutting edge ARM Cortex microcontroller and latest HF transceiver technology coupled with the reader's intelligent operating system make this module the most versatile HF RFID module at the bottom tier price point. The Gemini module's support for the secure MIFARE family of tags offer a low-cost and robust method of authentication for consumables. At about the size of a matchbook, this module can be fit into almost any new or existing OEM design. The Gemini module is also well suited for battery powered and other power sensitive applications because of the low power features including software stand-by mode and deep sleep mode. What's Included? Gemini Module NFC Reader Unit, USB A to USB micro cable, SkyeWare 4 Sample Software to read and write to NFC tags, SkyeTek Sample Tag Kit for NFC and MIFARE, 2 NXP MIFARE Plus X 4k Tags, 2 SNP Classic 1k Tags, 2 NXP NTAG 203 Tags, and 2 NXP MIFARE Ultralight Tags. SPECIFICATIONS ELECTRICAL: Air Interface Protocol: ISO 14443 A/B (parts 2-4), ISO 18092 Operating Frequency: 13.56 MHz Transmit Power: 125 mW Max Receive Sensitivity: N/A Max Read Distance: Up to 80 mm Max Read Rate: N/A Data Interface: USB, TTL serial, 12C, SPI GPIO: 4 Input/outputs Power Source: USB MECHANICAL: Antenna Ports: 1 port Antenna: Internal antenna Dimensions: 1.6 x 1.5 x 0.2 in (40 x 38 x 5 mm) Weight: 22.7 g ENVIRONMENT: IP Rating: N/A Operating Temperature: -20° to +70°C APPLICATION INTERFACE: Host API: SkyeTek API C, C #, .NET Demo Software: SkyeWare 4 developer interface
