SilverStone Technology 450W SFX Form Factor 80 Plus Bronze Power Supply with +12V Single Rail, Active PFC (ST45SF)
Type
Price
Date
Current Price
Out Of Stock
2024-06-19
Highest Price
$90.42
2022-10-11
Lowest Price
$79.99
2021-02-09

SilverStone Technology 450W SFX Form Factor 80 Plus Bronze Power Supply with +12V Single Rail, Active PFC (ST45SF)

Specifications

  • Mfr Part Number: ST45SF
  • Features:
    • Support standard SFX form factor and ATX via included bracket
    • 450W continuous power output at 50‚°C operating temperature rated for 24/7 operation
    • 80 PLUS Bronze level efficiency (82%~85% efficiency at 20%~100% loading)
    • Class-leading single +12V rail with 36A
    • Silent running 80mm fan with 18dBA minimum
    • Single PCI-E 8pin and dual PCI-E 6pin connectors support
  • Type: SFX
  • Maximum Power: 450W
  • Input:
    • Voltage: 90V ~ 265V
    • Frequency Range: 47 ~ 63Hz
  • Power Factor Correction: Active PFC (PF>0.95 at Full Load)
  • Efficiency: 82% ~85% at 20% ~ 100% Loading
  • MTBF: 100,000 hours at 25‚°C, full load
  • Fans: Single 80mm Silent Fan
  • Noise Level: 18 dBA Minimum
  • Output: +3.3V @ 21A, +5V@ 22A, +12@ 36A, -12V @ 0.5A, +5VSB @ 2.5A
  • Connectors: 1x 20+4pin Main Connector, 1x 4+4pin ATX/EPS 12V Connector, 3x SATA Connectors, 1x 6+2pin PCI-Express Connector, 1x 6pin PCI-Express Connector, 2x 4pin Peripheral Connectors, 1x 4pin Floppy Connector
  • Protection: Over Current, Over Power, Over Voltage, Under Voltage, Short Circuit
  • Color: Black (Lead-Free Paint)
  • Dimensions (WxDxH): 125.0 x 100.0 x 63.5 mm
  • Weight: 1.0 kg

  • TitleSilverStone Technology 450W SFX Form Factor 80 Plus Bronze Power Supply with +12V Single Rail, Active PFC (ST45SF)
  • BrandSilverStone Technology
  • ManufacturerSilverstone
  • BindingPersonal Computers
  • ProductGroupPersonal Computer
  • ItemPartNumberSST-ST45SF
  • ModelSST-ST45SF
  • Warranty1 YEAR
  • Size450W
  • UnitCount1
  • UPCs682017417325
  • EANs0844761006600
