Signswise High Quality Heavy Duty Mini Multipurpose 6 In1 Lathe Kit Jig-Improved version-Black

Feature

*The parts in the kit can be assembled into 6 kinds of machines with different function- jigsaw, wood-turning lathe, metal lathe, milling machine, drilling machine, sanding machine, hand-held machine, only one kind of machine can be assembled each time.
*Main parts: headstock, central block, jigsaw base, jigsaw casing, motor blade, gear, wood-turning chisel base, cross slider, big slider, drilling lever, drilling table, jigsaw table, connection piece, sanding paper panel, vice, drive belt cover, grinding wheel, wheel guard etc. All of the parts are made of metal except drive belt cover, grinding wheel and wheel guard.

Specification

*Motorspeed:20,000rpm/min(optional choice12,000rpm/min)
*Input voltage/current/power:12VDC/2A/24W
*Switching power input:AC110V-240V
*Jigsaw working table size:90mm*90mm
*Maximum working material diameter of metal lathe and woodturning lathe:50mm
*Working material length of metal lathe and woodturning lathe:135mm
*Slider travel : Axis X=145, Axis Y=32, Axis Z=32
*Collets:1-6mm
*Drilling working table size: 123*100mm
*Maximum workpiece size clamped by vice:50mm 10.Maximum workpiece diameter clamped by three-jaw chuck:50mm
*Center height of metal lathe: 25mm
*Working material thickness of jigsaw: hardwood 4mm, plywood 7mm

Note

All of the machines are safe touch except milling machines. It requests to be used under parents or teachers instruction when the milling machine is being used by the kids.

  • BindingMisc.
  • BrandSignswise
  • EAN0711508967572
  • LabelSignswise
  • ManufacturerSignswise
  • ProductGroupHome Improvement
  • ProductTypeNameTOOLS
  • PublisherSignswise
  • StudioSignswise
  • TitleSignswise High Quality Heavy Duty Mini Multipurpose 6 In1 Lathe Kit Jig-Improved version-Black
  • UPC711508967572
