Siglent SDG2122X Series Function/Arbitrary Waveform Generator
*SIGLENT's SDG2000X is a series of dual-channel function/arbitrary waveform generators with specifications of up to 120MHz maximum bandwidth, 1.2GSa/s sampling rate and 16-bit vertical resolution. The proprietary TrueArb & EasyPulse techniques help to solve the weaknesses inherent in traditional DDS generators when generating arbitrary, square and pulse waveforms. With advantages above, SDG2000X can provide users with a variety of high fidelity and low jitter signals, which can meet the growing requirements of complex and extensive applications. Key Features
*Dual-channel, 120MHz maximum bandwidth, 20Vpp maximum
*output amplitude, high fidelity output with 80dB dynamic range
*High-performance sampling system with 1.2GSa/s sampling rate and 16-bit vertical resolution. No detail in your waveforms will be lost
*Innovative TrueArb technology, based on a point-by-point architecture, supports any 8pts~8Mpts Arb waveform with a sampling rate in range of 1ÃŽSa/s~75MSa/s
*Innovative EasyPulse technology, capable of generating lower jitter Square or Pulse waveforms, brings a wide range and extremely high precision in pulse width and rise/fall times adjustment
*Plenty of analog and digital modulation types: AMã€ÂDSB-AM〠FMã€ÂPMã€ÂFSKã€ÂASK and PWM
*Sweep and Burst function
*High precision Frequency Counter
*Standard interfaces: USB Host, USB DeviceïˆUSBTMCï‰, LAN ïˆVXI-11ï‰
*Optional interface: GPIB
*4.3" touch screen display for easier operation
*Bandwidth :120MHz
*Sampling rate: 1.2 GSa/s (4X Interpolation)
*Vertical resolution: 16 bit
*Num. of channels: 2
*Max. amplitude: ±10V Display :4.3" touch screen display, 480 x 272 x RGB
*Interface Standard: USB Host, USB Device, LANOptional: GPIB (USB-GPIB adaptor)
