SainSmart UDB1005S 5MHz DDS Function Signal Generator, Source Frequency Counter DDS Module Wave, Rev3.0 PC Serial Ports

This SainSmart signal generator source module uses DDS technology and FPGA design with the characters of high stability and low distortion ect. It's the ideal equipment of electronic engineer, laboratory, production lines, teaching and scientific research.

Signal Output Function

* Output waveforms: Sine wave, Square wave and Triangle wave
* Output amplitude: ≥10Vp-p(signal output, no load)
* Output impedance: 50Ω±10%(signal output)
* DC offset: ±2.5V(no load)
* Display: LCD160
* Frequency range: 0.01Hz ~ 5MHz(UDB1005)
* Resolution: 0.01Hz
* Frequency Stability: ±1×10-6
* Frequency accuracy: ±5×10-6
* Sine wave distortion: ≤0.8% (reference frequency is 1kHz)
* Trinagle linearity: ≥98% (0.01Hz~10kHz)
* Rise and fall time of square wave: ≤100ns
* Square Wave Duty range: 1%~99%

TTL Output Function

* Frequency range: 0.01Hz ~ 5MHz (UDB1005)
* Amplitude: >3Vp-p
* Fan Out: >20 TTL loads
* 3.COUNTER function
* Counter Range: 0-4294967295
* Frequency Meter Range: 1Hz~60MHz
* Input Voltage Range: 0.5Vp-p~20Vp-p
* Storage and transferred: 10 set of parameters with storage and recall functions.

Package List:

1 x DDS signal generator
1 x DC 5V power adapter

Manual：

https://s3-ap-northeast-1.amazonaws.com/sain-amzn/20/20-010-502/UDB100xUsersManual.doc.zip
