SainSmart TGS813 TGS-813 Combustion Gas Sensor Methane Butane For Arduino Pi, Japan Figaro

The sensing element is a tin dioxide (SnO2) semiconductor which has low conductivity in clean air. In the presence of a detectable gas, the sensor's conductivity increases depending on the gas concentration in the air. A simple electrical circuit can convert the change in conductivity to an output signal which corresponds to the gas concentration.The TGS 813 has high sensitivity to methane, propane, and butane, making it ideal for natural gas and LPG monitoring. The sensor can detect a wide range of gases, making it an excellent, low cost sensor for a wide variety of applications. Also available with a ceramic base which is highly resistant to severe environments up to 200°C (model# TGS 816).

Features

* General purpose sensor with sensitivity to a wide range of combustible gases
* High sensitivity to methane, propane, and butane
* Long life and low cost
* Uses simple electrical circuit

Applications

Domestic gas leak detectors and alarms Portable gas detectors

The figure below represents typical sensitivity characteristics, all data having been gathered at standard test conditions (see reverse side of this sheet). The Y-axis is indicated as sensor resistance ratio (Rs/Ro) which is defined as follows:

Rs = Sensor resistance of displayed gases at various concentrations
Ro = Sensor resistance in 1000ppm methane
