SUNWIN 4 Axis E-Cut USB MACH3 Motion Control Card CNC Interface Breakout Driver Board

120M working frequency,Maximum step-pulse frequency is 1MHz,Perfectly drive servo and stepper motor in three ways:pulse/direction,CW/CCW,AB quadrature output.
Status indicator LED can be usefulto show the USB connection,and working status by flashing.
16 general-purpose inputs,PNP or NPN input status can be configured in Mach3.
8 electronic switch outputs.Darlington open-drain output.
Measures real-time spindle speed(Support the Hall element and quadrature encoder speed masurement,etc.)and spindle speed can be observed in March3 to perfectly support the application of spindle.Perfectly support the lathe spindle applications and other occasions,whitch requires precise spindle speed.
Use external 12V-24V DC power supply to isolate USB and external port,and to make the system more stable.
11 high-speed optical couplers with 10MHz,and 24 general optical couplers(Total optocoupler reach to 35)for isolating all of the input/output signals,isolation voltage up to 2KV
2 spindle export interface:accurate 0-10V analog output,supporting converter to control spindle drive;PWM output with 5V drop-down,providing PWM speed drive,CW/CCW output,puls/dir output and quadrature output for servo or stepping driver
The output spindle can be configured into any axis of the 4 shaft through the software
2 external adjustment-knob to adjust the processing speed,spindle speed and manual mode processing speed.
The 4 layers circuit board selected high-quality devices is exquisite
Pluse up to 1MHZ

What is in box ?
1 X 4 Axis MACH3 Motion Control Card
