S&D Perfect Gift!!!DC 12V Signal Amplifier For SMD 3528 5050 RGB LED Strip Light Lamp,One Year¡¯s Guaranty

Specifications:
Working temperature: -20-60¡¦
Supply Voltage: 12V DC/24V DC
Output Voltage: 12V DC
Power: Less than 144W
Output: 3 channel (Red, Green, Blue)
Connecting mode: common anode
Output Current: Less than 4A each channel
Static Power consumption: <1W (Needs an external 12V /24V source)
Housing Material: Aluminum alloy
Color: Silver
External dimension: L104*W64*H24.5mm
Packing size: L115*W70*H35 mm
Net weight: 120g
Gross weight: 170g

Application:
1.This amplifier (booster) is optional. It receive PWM signal RGB LED PWM signal from LED controller and send the signal to another group of LED source. You only need it if the load of the RGB ribbon or strips exceeds the rated output of the controller or decoder you will use. e.g. you may use one of this after every 5m SMD5050 60LEDs/m RGB LED Strips
2.For multiple strip lights in series conncetion, please use more repeaters. In theory,RGB amplifier can be connected to numerous.
3.A separate DC 12V/DC 24V power supply is required to power this amplifier, otherwise it won¡¯t function.
4.Either method for powering (the plug on the input side or the terminals on the side with the output) works.

Package:
1 x LED RGB Amplifier
2 x wire leads
2 x 4pin Male connectors
1 x User manual

Remarks:
NOT waterproof! Don't use them outdoors or where they can be subjected to excessive moisture.
It also comes with 2 extra 4 Pin Male connectors for reserve.
