RioRandCNC TB6560 4 Axis 3.5A Stepper Motor Driver Board Controller Engraving Machine

€Power supply DC 12-36V (not included, please feel free to contact us if you need !)
*This driver get its power from the same unit as the steppers, it doesn't require a separate power source.
*Voltage Selection:
12-16V DC power supply for Nema 17 stepper motors
16-24V DC power supply for Nema 23 stepper motors
24-36V DC power supply for Nema 34 stepper motors
(High voltage will burn up the chips or stepper motors!!!)
*Ampertage Selection:
Output current of the power supply can be calculated by the following expressions:
Output current = Rated current of your stepper motors * quantity + 2A
(For example, if you want to drive 3 * 3A Nema 23 stepper motors, theoretically 24V 11A DC power supply is recommended, but higher power such as 24V 15A also will be good.
If you are not sure about the selection of power supply, please feel free to contact us for help)
€The power output of 12V shall be applied to the radiator fan of 12V
€Driver output compatible with 2 or 4 phase, 4,6 or 8 lead stepper motors, 3A max.
€Suitable for unipolar or bipolar stepper motors.
€Voltage regulated spindle speed controlled by parallel interface as function of supply voltage.
Package List:
€1 x TB6560 Stepper Motor Driver 1.5A-3A
€6 x Wire connectors
€1 x DB25 parallel cable
€1 x CD software(English Manual & Mach3 demo version)
