Precision Twist C29HX10 High Speed Steel Jobber Length Drill Bit Set, Purple and Gold Oxide Finish, 135 Degree Point, Inch, 29 Piece, 1/16
Type
Price
Date
Current Price
Out Of Stock
2023-06-30
Highest Price
$258.01
2022-08-18
Lowest Price
$258.01
2022-08-18

Precision Twist C29HX10 High Speed Steel Jobber Length Drill Bit Set, Purple and Gold Oxide Finish, 135 Degree Point, Inch, 29 Piece, 1/16" to 1/2" x 64ths

This Precision Twist C29HX10 jobber length drill bit set contains 29 high-speed steel drill bits, including inch sizes 1/16" through 1/2" in 1/64" increments, with a purple and gold oxide finish and a 135-degree split point for general-purpose applications on a range of materials. High-speed steel (HSS) provides hardness for wear resistance, and the purple and gold oxide finish provides additional wear resistance compared to an uncoated drill bit. Compared to standard drill bits, these tools have a thicker web for increased strength and rigidity. The self-centering 135-degree split point penetrates hard material without a pilot hole and produces smaller chips, which are less likely to clog a hole than a 118-degree point. These jobber length drill bits have a drilling depth up to four times their diameter. The round shank accommodates most drill chucks. The set comes in a metal index case with labeled compartments for identification and organization. Drill bits conform to American National Standards Institute (ANSI) standards.

Drill bits are cutting tools used to make holes in a range of materials using machines such as handheld portable drills, machining centers, and lathes. Drill bits come in a variety of lengths and types, the most common of which is the twist drill bit. The round, twisted shaft of the twist drill bit typically has two cutting edges and flutes. The helical twist of the flutes brings chips up and away from the cutting edges and allows for coolant to reach the cutting edges. Jobber length twist drill bits, the most common length of twist drill bit, offer a good compromise of length and reach to work with the widest range of materials and applications. Mechanic's length twist drill bits (also called maintenance length) are a little shorter than jobber length and less prone to deflection when drilling. Short length twist drill bits (also called stub or screw-machine length) are the shortest and stiffest twist drill bits, helping to reduce the chance of deflection or breakage when drilling. Reduced shank drill bits (also called Silver and Deming drill bits) have a shank that is smaller in diameter than its shaft, permitting drilling machines with either a 1/2" or 3/4" drill chuck to create large holes. Long length twist drill bits (also called taper length) are a little longer than jobber length, allowing for deeper holes and longer reach. Extra long twist drill bits (also called extension) are longer than long length twist drill bits for greater reach or for drilling deeper holes.

Precision Dormer manufactures cutting tools under the brands Precision Twist, Dormer, and Union Butterfield. The company, headquartered in Crystal Lake, IL, meets International Organization for Standardization (ISO) standards 9001 and 14000.

What€s in the Box?

  • 29 drill bits, inch sizes 1/16" through 1/2" in 1/64" increments
  • Metal case

  • TitlePrecision Twist C29HX10 High Speed Steel Jobber Length Drill Bit Set, Purple and Gold Oxide Finish, 135 Degree Point, Inch, 29 Piece, 1/16" to 1/2" x 64ths
  • BrandPrecision Twist Drill
  • ManufacturerPrecision Dormer
  • BindingMisc.
  • ProductGroupBISS
  • ItemPartNumberC29HX10SET
  • Model091010
  • Size1/16" - 1/2" x 64ths
  • UnitCount1
  • UPCs086071910103
  • EANs0086071910103
