Powermatic 1792000K Model PM 2000 3 Horsepower Cabinet Saw with 50-Inch Accu-Fence, 2 Cast Iron Extension Wings, Table Board, and Legs, 230-Volt 1 Phase
Powered by a three-horsepower, one-Ph motor, the award winning Powermatic PM2000 10-Inch Cabinet Saw sets a new standard for innovation with an array of patented features and massive body design. It boasts the heaviest cast-iron base in its class to virtually eliminate table vibration, oversized cast-iron tables, and a push-button arbor lock that's conveniently accessible from above the tabletop.
| ||||
 The cast-iron base features a built-in, retractable, 4-wheel caster system. View larger. |
 Oversized, cast-iron hand wheels for quick blade adjustment. View larger. |
 The push-button arbor lock allows for rapid blade changes. View larger. |
 The built-in dust collection system ensures long motor life. View larger. |
Its refined heavy-duty trunnion mechanism features rigid, box-style cast-iron construction, high-end bearings, and a conical-shaped worm gear drive with an increased contact area to enhance the smooth, solid feel of the tilt and height adjustment.
A pair of oversized, eight-inch-diameter cast-iron hand wheels, each with a large spinner handle, makes blade height and bevel adjustments virtually effortless. And to prevent long-term use from loosening the hand wheels on their shafts, they are locked in place with machined grooves and keys rather than setscrews.
Precision Machined Arbor and Poly-V Drive Belt System
The full-length 5/8-inch diameter arbor is precision machined from stress-proof steel to exceptionally high tolerances for accuracy. It accepts stacked dado sets up to 13/16-inch wide, and because there is no gap between the threads and arbor shank, thin chippers won't hang out of line.
Also, the push-button arbor lock makes for rapid blade changes, while a high quality poly-V drive belt system transmits more power without slippage or excessive noise.
Generously Sized Tables and Extensions
All the high-luster, cast-iron surfaces are finely ground to ensure a smooth, mar-free work surface that provides more support for big jobs and have both a front- and rear-edge bevel for hassle-free work piece positioning.
Measuring approximately 30.5 x 22.0 inches (W x L), the primary cast-iron tabletop expands to 42 inches long when the standard cast-iron extension wings are bolted up, giving you plenty of space for even large work pieces.
Safe, Sturdy Design
The PM2000 also comes equipped with a newly designed magnetic On/Off switch for safety. To prevent accidental start-ups, there's a removable magnetic "key" that disables the switch when it's not in place. For additional protection against damage, a quick-release riving knife greatly reduces binding/kickback risk.
High-Tech Guard System
The PM2000's blade guard and riving knife system can be adjusted tool-free for the job at hand. At the same time, because the riving knife is mounted directly to the blade mechanism, the gap between it and the blade never changes during height or angle adjustments.
This maintains the safety a riving knife affords in virtually all cutting situations.
Get Accuracy and Precision
An industrial-duty 50-inch Accu-Fence System ensures accurate cuts. Adjustable angle indicators on the blade bevel scale for repeatable bevel cuts. Additionally, a heavy-duty, deluxe, micro-adjust miter gauge with a 13-inch extension fence ensures stable workpiece support and easy fine-angle adjustments.
Finally, to facilitate movement in and around the shop, the massive cast-iron base has a built-in retractable, four-wheel caster system.
Dimensions and Warranty Information
The PM2000 measures 37 x 39 x 85 inches (W x H x D), weighs 675 pounds, and is backed by a five-year warranty.
What's in the Box
One table saw; one table insert; one miter gauge assembly; one blade guard assembly; one switch in box; one push stick; one arbor wrench; two lock knobs; two swivel handles; one riving knife and pawl assembly; one hardware bag; two extension tables packed in individual boxes; two hinge pins; one side cover; manual; and warranty card.
