Panlong Optical TOSLINK / Coaxial SPDIF Audio Switch Selector Box 4 In 1 Out with Analog RCA and 3.5mm Headphone Out

This is a 4-Port SPDIF audio switcher as well as a digital PCM to analog audio converter. You can switch among four digital audio inputs to the Toslink audio output. At the same time, it can convert digital stereo PCM/LPCM audio to analog for RCA L/R and headphone output.

Note: it is not an audio decoder; if selected digital audio input is multi-channel (Dolby Digital, DTS), RCA L/R and headphone ouputs will not have sound. Remote control not included.

Features:
1. 4x SPDIF digital audio inputs (2xToslink and 2xCoaxial), switch to one SPDIF/Toslink output.
2. Support PCM/LPCM digital audio converted to L/R analog audio output and headphone output. Uses 192KHZ/24bit DAC for superb audio quality.
3. Support digital audio formats: Dolby AC3, DTS, THX, HDCD, LPCM for SPDIF output.
4. Automatically identifies input digital audio signal format; when input is non-LPCM (>2CH), analog output will be mute.
5. Input status indication. When no audio or wrong data input, the input port indicator starts to flash.
6. Dual-function button for input selection and power on/off: push to switch input; push & hold for 3 seconds to power off the switcher; then push to power on.
7. High tone quality, low noise, power-off memory.
8. Plug and play; Installs in minutes.

Package Includes:
1x 4-Port SPDIF Audio Switch
1x DC 5V Universal 100V - 240V Power Adapter (US plug)
1x User Manual

  • TitlePanlong Optical TOSLINK / Coaxial SPDIF Audio Switch Selector Box 4 In 1 Out with Analog RCA and 3.5mm Headphone Out
  • BrandPanlong
  • ManufacturerACE DEAL INC.
  • BindingElectronics
  • ProductGroupElectronics
  • ItemPartNumberPL-SW0401C
  • ModelPL-SW0401C
  • EANs6954376104593
