Online-Metal-Supply-3003-Aluminum-Expanded-Flattened-Sheet-12-051-x-12-x-24--500-SWD--127-LWD-313-SWO--1-LWO

Expanded metal sheets are created by slitting and cold-forming metal as it expands in a press. This creates diamond-shaped openings that are nominally measured the long way of the diamond (LWD) and the short way of the diamond (SWD) and long way of the opening (LWO) and short way of opening (SWO) . Flat expanded sheets have been rolled for a smooth, level surface which slightly increases the overall thickness of the sheet from the original material thickness.

  • Material: Aluminum 3003
  • Finish: Unpolished (Mill)
  • Thickness: .051 inch
  • Width: 12 inches
  • Length: 24 inches
  • Long Way of Diamond (LWD): 1.27 inches
  • Short Way of Diamond (SWD): 1/2 inch
  • Long Way of Opening (LWO): 1 inch
  • Short Way of Opening (SWO): .313 inch
  • Open Area: 61%
  • Hole Shape: Diamond
  • Thickness Tolerance: +/-.001
  • Width Tolerance: +/-1/8
  • Length Tolerance: +/-1/8
  • Notes: None

  • BrandOnline Metal Supply
  • EAN0735926177078
  • LabelOnline Metal Supply
  • ManufacturerOnline Metal Supply
  • MPN735926177078
  • NumberOfItems1
  • PackageQuantity1
  • PartNumber735926177078
  • ProductGroupBISS
  • ProductTypeNameRAW_MATERIALS
  • PublisherOnline Metal Supply
  • StudioOnline Metal Supply
  • TitleOnline Metal Supply 3003 Aluminum Expanded Flattened Sheet 1/2 .051 x 12" x 24" - .500" SWD - 1.27" LWD (.313" SWO - 1" LWO)
  • UPC735926177078
