OTOWA LT-C32G801W LED Light/Machine protection SPD (Class 2) OT

[SPD according to IEC61643-11] Class II
[Nominal AC voltage UN] 3 phi Y: 250Vms, 3 phi delta: 250Vms
[Max. continuous operating a.c. voltage Uc] 3 phi Y: 275Vms, 3 phi delta: 275Vms
[Nominal discharge current In] 2.5kA
[Max. discharge current Imax] 5kA
[Voltage protection level Up] <= 1500V
[Response time] 3ns
[Application system] 3Phase
[Mode of protection] Common & Differential Mode
[Operating temperature range] -20CEL to +70CEL
[Operating state/fault indication] Green/ Red
[For mounting on] M4 screw
[Cross-sectional area (Max.)] AWG16 x 250mm
[TOV characterisics] Safe mode failing
[Enclosure material] Polycarbonate Black UL94 V-0
[Location category] Indoor
[Degree of protection] IP20
[Certification] UL1449 Ed.3 / CSA / TUV
[Standards comply with] EC 61643-11 JIS C 5381-1
[Weight] approx. 65g
