Noyafa NF-388-B Multipurpose Network Cable Tester Tracker Tracer Test Ethernet
NF-388 is a practical cable Test & inspection instrument with lots of new functions researched and developed by Noyafa.It highlights for its two scan modes, Tone tracking & port flashing.
It includes 8 remotes, which brings high work efficiency.Thus, it becomes available tool for technicians in installation and maintenance of weak current system.
It is widely applicable to telephone system, computer network and other fields.
NF-388 Transmitter specification
Tone frequency:455kHz
Max. distance of transmission:2km
Max. distance of cable map:300m
Max. working current:70mA
Tone mode:2 Tones adjustable
Compatible connectors:RJ11ïŒRJ45,BNC, USB
Max. signal voltage:15Vp-p
Function and faults LCD displayïšLCD display (wiremap, Tone, short,No adapter, Low battery)
Cable map indication:LCD (#1-#8)
Shielded indication:LCD ( #G)
Battery Type:DC9.0V x 1pcs
Dimension(LxWxD):185x80x32mm
NF-388 Receiver specification
Frequency:455kHz
Max. working current:70mA
Battery Type:DC9.0V x 1pcs
Dimension(LxWxD): 218x46x29 mm
NF-388 Remote unit specification
Compatible connectors: RJ45,BNC
Remote identifier: 8pcs
Dimension(LxWxD):107x30x24mm
