New CNC 6 Axis USB Mach3 Card Controller Breakout Interface Board Driver 200khz

DDSMXV5.0 is designed by our Studio, it is a CNC system based mach3.It's version is 5.0 now.You do not need to add other HardwareïŒand you can complete the signal conversion from the G-code to the movement of the stepper motor drive control. This card is compatible
with most stepper drives and servo drives. And it is perfect weapon to replace mach3 parallel interface board. DDSMXV5.0 include DDSM3V5.0 、 DDSM4V5.0 、 DDSM5V5.0 、 DDSM6V5.0ïŒthey are 3、4、5、6 axes mach3CNC card. These 4 cards use the same Hardware platformDDSMXV5.0.They are limited to 3,4,5,6 axes for different voice of customer .They use the same manual.
1. Simultaneously control 3 stepper motors.
2. With 24 programmable input interface , can be configured to be "limit", "E-stop" and other functions.
3. With 14 programmable output interface, can work with water-cooling or mist-cooling spindle and other devices.
4.. PWM/VSOïˆ0-10Vï‰ spindle control mode .
5. USB interface, support MACH3 software.
6. DCDC electrical isolation
7.With maximum 200KHZ stepper motor pulse control output , suitable for most machine system.
8.Dimensionsïš120*72*20mm
9.Weight:180g
Requirements of Computer
Basic Configurationïš
1)CPUïš1GHzï›
2)Memoryïš512MB
3)500MB Available disk space
4)USB 2.0
Recommended configurationïš
1)CPUïš2GHz Dual Coreï›
2)Memoryïš2GBbr>
Package include:
1 x New 200KHz 6 Axis CNC USB Mach3 Card Controller Breakout Interface Board Driver
1 x USB cable
1 x CD
