New ARM11 Based Win CE 6.0 Thin Client Net Computer Mini PC Share Sharing Station Network Terminal with 3 USB Ports
Data sheet
1. Operating System: Windows CE 6.0
2. CPU: Onboard CPU ARM11 CLG7700 800MHz
3. RAM: Onboard 128MB
4. Flash: Onboard SLC 128MB MLC 2G
5. Display support Max 1280*1024, 32bit/64K colors; Widescreen 1440*900 support,24bit true color support
6. Power Input: 100-240V, 50/60Hz; Output: 5V/2A
7. Management Remote management, configuration;
8. Wake terminal remotely(Wake-on-LAN)
9. Onboard LAN 10/100 MB/s
10. Operating range 3k meters
11. Ports: 1 RJ-45 LAN port; 3 USB 2.0 ports; 1 DC in port; 2 Audio jacks: Speaker-out and mic-in;
12. Server OS support Win 2000/2003/2008/XP/Vista/Win 7 professional version
Host PC Configuration
1 Remote User: Pentium 4, >1.3 GHz, 512 MB RAM
2-3 Remote Users: Pentium 4 (HT), >2.4 GHz, 512 MB RAM
4-7 Remote Users: Pentium 4 (HT), >3.0 GHz, 1 GB RAM
8-10 Remote Users: Pentium 4 (HT), >3.2 GHz, 2 GB RAM
11-14 Remote Users: Intel P4,>3.2GHz,3GB RAM
15-20 Remote Users: XEON 2.8GHz or XEON 2.4GHz Dual, 3GB RAM
21-30 Remote Users: XEON 3.2GHz or XEON 2.8GHz Dual, 4GB RAM
31-50 Remote Users: XEON E5506*2, 4GB*4 DDR3/1333 ECC REG
51-70 Remote Users: XEON E5506*2, 4GB*6 DDR3/1333 ECC REG
71-100 Remote Users: XEON E7520*2, 16GB*4 DDR3/1333 ECC REG
