Neewer 4076/3Y 1550KV Sensorless Brushless Motor and 150A Sensored Speed Controller ESC for 1/8 RC On-road / Off-road Car

4076/3Y 1550KV Sensorless Brushless Motor:

4 Pole 12 Slot Hi-torque Motor Design

CNC Machined 6061 T6 Billet Aluminum Heatsink Can

High Purity Copper Windings maximizes Efficiency

High RPM ABEC5 Oversized Bearings

Universal fit, fits all 1/8 brushless cars-multi-mounting system for M3 or M4 screws

Precision balanced rotor, smoothness for best reliability and maximum RPM

Stator-Super Thin (0.2mm) Laminations

Removable/Replaceable Rotor

ROAR Legal

Precision Engineered for Maximum Energy Conversion

Watts: 2800W

Max Voltage: <26V

Max Amps: 108A

LO: 1.2A

Resistance: 0.0131

KV(RPM/Volt): 1550

Max RPM: 50000

Length: 76mm

Diameters: 40/42mm with fins

Weight(g): 405

Shaft(mm): 5

Length of Extend Shaft: 20mm

150A Sensored ESC:

Enhanced throttle response, excellent acceleration, strong brakes and throttle linearity

Using advanced PC software interface to set up or update the software

Using LED program card to make adjustments

Adjustable BEC output 6.0V/8.4V

Multiple protection features: Low voltage cut-off protection, over-heat propection and throttle signal loss protection

Compatible with NOVAK, LRP, ORION brushless motor

Cont.Current: 150A

Burst Current: 1080A

Resistance: 0.0002 ohm

Suitable Car: 1:5&1:8 on-road and off-road cars/ trucks for competitive race

Motor Type: 4Pole Sensored/Sensorless brushless motor

Battery: 5-18cells NiMh, 2-6S Li-po

BEC Output: 6.0V, 8.4V adjustable /3A

Dimension(with out fan): 2.1x 1.9x 1.4inch/55x48x37mm

Weight: 5.6oz/159g

Package Contents:

1x Sensorless Brushless Motor

1x 150A Sensored ESC
