Nady MM-242 4 Stereo / 8 Mono Channel Mini Mixer with mono/stereo mode, ¼” Inputs and outputs – battery powered, or use optional AC adapter
Dozens of applications for this extremely useful mixer at a very affordable price
The Nady MM-242 allows you to easily combine mono or stereo signals together and adjust their relative volumes. Ideal for DJ equipment, synths and guitar rigs, studio, stage, the MM-242 is a great tool to have around everywhere. Mono/stereo mode selector switch determines whether all 8 inputs are mixed to both 1/4" outputs or are preserved as stereo signals, so you have greater flexibility and mixing options. Connect the € outputs of this little workhorse directly to your PA or recording device for ultra-clean audio. Eliminate the need for bulkier, more expensive mixers, and take the MM-242 anywhere with you with its 9VDC operation using either a 9V alkaline battery or the optional PAD-1 AC/DC external adapter.
Specifications
Input Impedance: 50k„¦
Output Impedance: 120„¦
Maximum Output: +7dBm
Frequency Response: 20Hz-30kHz
THD: 0.07%
S/N: -95dB
Noise Floor: 120uV
Inputs/Outputs: 1/4€ unbalanced
Peak LEDs: light 3dB before clipping
Current Drain: 19mA
9V Battery Life: up to 35 hours
Power Requirements: 9V battery or optional PAD-1 AC/DC adapter
