Meriam M200LS-GI0500 Lab Standard Smart Manometer, Gauge Pressure, 0-500 psi Range, + or - 0.01% Accuracy Full Scale, 1/8" NPT Female Connection, Battery Operated
The Meriam M200LS-GI0500 Smart portable digital manometer has a non-isolated differential sensor performs gauge pressure measurements. The meter has a measuring range of 0 to500 psi. NIST traceable accuracy of + or - 0.01% of full scale includes all effects of linearity, repeatability, hysteresis, and temperature from 59 to 86 degrees F (15 to 30 degrees C). The 1/8" female NPT connection is composed of 316L stainless steel and brass parts and has Viton O-rings for use with clean, dry, non-corrosive gases. Engineering units include inches of water, psi, mm of Hg, inches of Hg, mbar, bar, kPa, kg/cm2, cm of H2O, and user-selectable scaling. The meter can be field-recalibrated for zero, span, and linearity with one- or five-point calibration. Leak test feature allows users to view Min/Max pressure values and calculate the leak rate per minute in pressure units when pressure testing pneumatic systems. Exponential damping has a user-selectable time constant from 0.1 to 25 seconds to minimize the effect of pulsating pressures.
The keypad has a sealed membrane to protect the instrument from contamination, and five dome contact-style buttons to ease operation. The two-line LCD shows 5 significant digits, and has contrast adjustment for use in a variety of lighting situations. The two-stage backlight provides visual indication of over-range measurements. The display can read out in any of eleven pressure units, or can be linearly scaled for user-selectable scaling. The meter has a square root flow function to display flow rate in user-defined units. An adjustable damping feature minimizes the effects of pulsating pressures. A Min/Max function captures the extremes of pulsating or varying pressure signals, and a Hold function freezes the display at any point of interest. Auto Record retains up to 240 readings for future recall. The meter has automatic shut-off at user-selectable times of 10, 20, 30, 45 or 60 seconds to extend battery life. The polycarbonate case is permanently static dissipative to provide ESD protection. The meter includes a rubber boot to protect against accidental bumps or drops.
| Specifications | |
|---|---|
| Pressure types | Gauge |
| Media compatibility | Dry, non-corrosive gases |
| Pressure range | 0 to 500.000 psi |
| Accuracy | NIST traceable to + or - 0.01% of full scale from 59 to 86 degrees F (15 to 30 degrees C) |
| Wetted parts material | 316L stainless steel and brass, with Viton O-rings |
| Engineering units | Inches of H2O (selectable at 4 or 20 degrees C, or 60 degrees F), psi, mm of Hg, inches of Hg, mbar, bar, kPa, kg/cm2, cm of H2O, and user-selectable scaling |
| Pressure limits | Twice range when pressurized on high side only, and 150 psi (10.5 Kg/cm2) static when applied to both sides of the sensor simultaneously |
| Case material | Dissipative polycarbonate case with rubber boot |
| Connection | 1/8" female NPT, 316L SS |
| Operating temperature | 59 to 86 degrees F/15 to 30 degrees C |
| Power requirements | Four AA alkaline batteries |
| Dimensions | 6.5 x 3.6 x 2.25 inches (H x W x D) |
H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back.
Meriam manufactures process measurement instrumentation including manometers, pressure gauges and transmitters, hand pumps, and flow indicators for the oil and gas, chemical, petrochemical, and automotive industries. The company, founded in 1911, is headquartered in Cleveland, OH.
