Mason HD-B-RED Rubber Double Deflection LDS Hanger Vibration Isolator for Rod Attachment, 235lbs Capacity, 0.40" Deflection, Red
HD Hangers are double deflection units with average static deflections of 0.40". Double deflection LDS rubber element with a projecting bushing to prevent steel to steel contact. They are molded in LDS because of its excellent aging characteristics. If you wish to isolate primary vibration, they should only be considered for smaller equipment running above 800 RPM in non-critical areas. The principle function of HD Hangers is noise isolation. 50 Durometer, 3" Lower rod penetration. 3/4" Maximum rod diameter. 0.40" Maximum rated deflection. Vertical G rating tension: 10.0+. Vertical G rating compression: 10.0+. Measures 4-1/4" width by 4-1/2" height by 3-1/4" depth.
