Martin Roller Chain Sprocket, Reboreable, Type B Hub, Single Strand, 06B Chain Size, 9.525mm Pitch, 10 Teeth, 8mm Bore Dia., 35.03mm OD, 20mm Hub Dia., 5.21mm Width
Type
Price
Date
Current Price
Out Of Stock
2024-10-10
Highest Price
-
-
Lowest Price
-
-

Martin Roller Chain Sprocket, Reboreable, Type B Hub, Single Strand, 06B Chain Size, 9.525mm Pitch, 10 Teeth, 8mm Bore Dia., 35.03mm OD, 20mm Hub Dia., 5.21mm Width

The Martin metric type B sprocket is suitable for use with series ISO 06B-1/metric 35 chain with 9.525 mm (0.375€) pitch for driver or driven sprocket applications. Varying numbers of teeth, pitch diameters, and stock bore sizes offer application flexibility. Made from high carbon steel, it has high strength and durability.

Type B sprockets have a hub extension on one side to provide stability and allow for the use of full-depth keyways and standard setscrews to attach the sprocket. They also can accommodate a wide range of shafts.

The chain data for this class of sprockets is BS 228/3, ISO 06B-1; pitch is 9.525 mm (0.375€); roller diameter is 6.35 mm (0.375€); roller width is 5.72 mm (0.225€); and tensile strength is 910 kg (2,000 lbs).

The options for this class of sprocket are: number of teeth from 8 to 114; pitch diameter from 24.89 mm to 345.68 mm; stock bore size of 8 mm to 19 mm; maximum bore size from 9 mm to 52 mm; hub diameter from 13 mm to 75 mm; length through bore size from 22 mm to 30 mm; and approximate weight from 0.03 kg to 3.63 kg. The tooth width is 5.31 mm (0.209€) nominal. Maximum bores will accommodate standard keyseat and setscrew over keyseat. Slightly larger bores are possible with no keyseat, shallow keyseat, or setscrew at angle to keyseat. All Martin sprockets meet or exceed ANSI standards.

A sprocket is a wheel with teeth around the perimeter that meshes with a chain, track, or other perforated or indented material. Unlike gears that mesh with another gear, sprockets mesh with a chain, which then interacts with another sprocket. Gears can be used to transmit power around a corner, based on how they fit together. Sprockets with chains only work in straight lines. Some common benefits of chain-drive systems include minimal slippage, a fixed ratio between rotating shafts, and versatility with many different chain attachments and sprocket material selections. An example of a power transmission system is a standard bicycle, which has a sprocket and a chain to deliver power from the rider€s legs to the wheels making the bike move.

Martin Sprocket & Gear manufactures power transmission and conveying products. The company was founded in 1951 and is headquartered in Arlington, TX. Martin provides tools that meet American National Standards Institute (ANSI), National Aerospace Standard (NAS), and Deutsches Institut fr Normung (DIN) standards.

  • TitleMartin Roller Chain Sprocket, Reboreable, Type B Hub, Single Strand, 06B Chain Size, 9.525mm Pitch, 10 Teeth, 8mm Bore Dia., 35.03mm OD, 20mm Hub Dia., 5.21mm Width
  • BrandMartin
  • ManufacturerMARTIN
  • BindingMisc.
  • ProductGroupBISS
  • ItemPartNumber06B10
  • ReleaseDate2017-05-15T00:00:01Z
  • Size06B
  • UnitCount1
  • UPCs697950395364
  • EANs0697950395364
