Mach3 Cnc Breakout Board Motion Controller Ethernet Smooth Stepper Cm-126ESS

* Features.
· 4-Axis Dir/Pulse Lines Driver Output.
· Relay No(Normal Open / Contact, A) Output 7
· Limit & Home Switch or Sensor Input 18
· DC Input Power +24V, 2000mA
· DC Voltage Output for Controlling for Spindle Speed. 0~10V or 0~5V Selection.
· Included Ethernet(Lan) Cable

-------------------------------------------------------------------------------------------------------------------

If you search "cnc4youstore" in google, you can find the Manual easily.
We want you to look around English User's Manual (.Pdf files) but Amazon system does not allow to link it here.
Usage is well-described inside there for you together images.
We recommend you read it first. If you contact us, will send you in advance though not purchasing.

- User's Manual -------------------------------------------------------------------------------------------------

- A table of Contents. All are 21 pages, .pdf file

- Install, Plug-in
- Set-up, Ethernet
- Set-up, Mach3

- Detailed Function
a. Switch or Sensor Input Port
b. Speed Control of Spindle & Relay Port for Controlling Exterior Device.
c. Port Connecting to Driver. Ex) Samsung servo
d. Power Input Port.

- Mach3, Run Screen
- Mach3, Set-Up
- Motor Tuning.
- How to Adjust Spindle Speed
- Further Information
