MX-1 Ultrasonic Wall Thickness Gauge, Complete Kit, Range: 0.025 - 19.99 " / 0.63 - 199.99 mm

The MX-1 will hold a single velocity, making it the perfect choice applications where only one material is being tested day after day. With the preset velocity in the gauge, you simply turn it on and go to work. The tool's backlit display is easy to read, even in dim light conditions, and the unit operates for up to 200 hours on a single set of AA batteries. The MX-1 comes complete, ready to use, and is protected by Dakota Ultrasonics 5 year limited warranty.   Features   Multi-function 4.5 digit liquid crystal display with 0.500 inch numerals, backlit for use in poor light conditions. Measurements displayed in inches, inches/microsecond, millimeters, and meters/second. Measures from 0.025 to 19.999 inches (0.63 to 199.99 millimeters) switch to select English or metric units. Four readings per second for single point measurements. IP 65 Rated [custom1]     Measuring Range 0.025 to 19.999 inches 0.63 to 199.99 millimeters Resolution 0.001 inch 0.01 millimeter Velocity Range 0.0492 to .3937 in/?s. 1250 to 10,000 meters/sec Dimensions 2.5 W x 4.75 H x 1.25 D inches Range in Steel 0.040-6.000" (1.00-150.0 mm) with supplied probe. Other probes available. Resolution .001" (0.01 mm) Display 4½ - Digit, 0.5" Backlit LCD Probe 1/4", 5 MHz, actual wearface is 5/8" (17mm) Cable 4 ft. (1.2 m) waterproof cable with non-polarized, quick-disconnect connectors. Optional lengths up to 50 ft. (15 m). Temp. Limits Ambient: -20 to 120° F (-30 to 50° C) Material: -0 to 200° F (-20 to 100° C Special high temperature probes are optionally available. Battery Type Two 1.5V alkaline or 1.2V NiCad AA cells. Battery Life Typically operates for 200 hours on alkaline and 130 hours on NiCad. Weight 10 ounces (283 g) Accessories Included Probe/cable assembly. 4 oz. bottle of coupling fluid, NIST Calibration Certificate, 2 AA batteries, operating instructions, hard-plastic carrying case. Warranty Gauge: 5 Years Probes: 90 Days [/custom1]
