MKELE High Reliable 12v 25a 300w Din Rail Power with the Function of Measuring LP-300-112

Model: LP-300W-12 DC output voltage: 12V Output voltage tolerance: 1% Rated output current: 25A Output current range: 0~25A Output power: 300W Ripple and noise: 240mVp-p Adjustable DC voltage range:10.8~13.2V INPUT Input voltage range 85~132VAC/176~264VAC(switchover) or 248~373VDC 47~63Hz AC input current 5.7A/115VAC 2.9A/230VAC Efficiency 85% 86% Impulse current Cold starting current: 15A/115VAC 30A/230VAC Leakage current <2mA/240VAC PROTECTION Overload protection 110%~150% Protection mode: cut off output and reset automatically Overvoltage protection 27~30V 51~54V Protection mode: cut off output and reset automatically ENVIRONMENT Work temperature, humidity -10C~+50C;20%~90 %RH Storage temperature, humidity -20C~+85C;10%~95 %RH Shock resistance 10~500Hz,2G 10min./1 cycle,duration: 60min, each shaft SAFETY Voltage withstand capacity Input-output: 2KVAC Input-earth: 1.5KVAC Output-earth: 0.5KVAC Insulation resistance Input-output, input-earth, output-earth: 100M Ohms/500VDC OTHERS Weight 0.74KG Package Outline size 100*60*110mm(L*W*H) According to your order,we can provide different cartons for you. NOTE: 1. All parameters, except special situation, are measured under 230VAC voltage input and rated load at 25C. 2. The ripple and noise voltage are measured in condition that capacitance of 0.1 and 47 are applied to ends of 12inch twisted-pair of 20MHz bandwidth oscilloscope. 3. The tolerance is the sum of setting voltage error, voltage and current regulation factor.
