MISOL Hybrid Solar Wind Charge Controller 600W 24VAC/ Wind Charge Controller/Wind Regulator/Solar Regulator

It is used for the wind turbine 600W with 24VAC output
PERFORMANCE FEATURES:
- Perfect protection function, thus the system has higher reliability.
- LCD display
- Voltage limiting and current-limiting charge mode ensures battery in the best charging status
- Two DC Load output, light-control, time-control, constant output, and multiple output control mode selection
- PWM mode

TECHNICAL PARAMETERS:
Rated Battery Voltage 24V
Rated Wind Turbine Power 600W
Max. Wind Turbine Power 900W
Wind Turbine brake Current 30A
Dump load start voltage:27 V
Complete discharge voltage: 29V
Battery under voltage shut off: 21.6V
Battery under voltage recover: 24v
Input over voltage shutoff: 32v
Rate output current of load 1 and load 2: 10A
Rated Solar Powe 300W
Control Mode PWM
Display Parameters:Wind Turbine Power, Wind Turbine Voltage, Wind Turbine Current, PV Voltage, PV Charge Current, PV Power, Battery Voltage,Over Voltage, UnderVoltage, OverLoad, Short Circuit, Night. Etc
Working Temperature &Humidity: -20~+55 cel.degree/ 0~93%RH(Without Condensation)
Temperature Compensation(optional): 4mV/cel.degree/2V, -35--+80Cel.degree, Precision:+/-1cel.degree
Protection Function: Solar reversechargeprotection,Solar reverseconnection protection,Battery overcharge protection,Battery overdischarge protection,Battery reverseconnection protection, Lightning protection Wind turbine current limiting,
Optional Function 1: RS Communication and Matched Software.
Optional Function 2: Low Voltage Charge Function.With this function.
