MISOL 1PCS of Motorized Ball Valve 1/2"(BSP) DN15 / 12VDC / 2 Way/Electrical Valve/Ball Valve with acuator / CR02


Application:
1.HVAC
2.Water treatment
3.Chemical process
4.Small equipment for automatic control
5.Replacing solenoid valve, particularly when solenoid cannot work reliably

Features:
1).Smart shape, Perform reliably, large output torque, as long as 50000-100000 times. multi-angel assembling, convenience for all kinds of requirements.
2).Float ball design, no leak, most suitable for heavy dirt and long time no action.
3).The conditions that solenoid valve can not be worked.
4). Under the pressure between 1Mpa and 2Mpa, the working current is only 45mA to 100mA (it depend on the different type)
5). High protection class, can be worked in moist conditions.

Technical Parameter:
Nominal Size: DN15 (1/2" BSP), reduce port
Pressure: 1.0MPa
Body: Brass ball valve
Medium temperature: -20 < t <100 cel.degree
Enclosure: IP65
Work voltage: DV12V
Input power: MAX. 4W
Working current: 60-80mA
nominal torque: 2N*M
Open/Close time:5 second
Wire type: CR02(3 wires), function as below:
1.Connecting SW and OPEN, the valve opens, getting the position, automatically power off, the valve remain fully open position.
2.Connecting SW and CLOSE, the valve close, getting the position, automatically power off, the valve remains side passes position (fully closed)
