Leegoal L298N Stepper Motor Driver Controller Board Module

Product parameters: Driver chips: L298N dual H-bridge DC motor driver chip 2. Driven part of the terminal supply area Vs: +5 V to +35 V; take power if required board, the supply area Vs: of +7 V ~~ +35 V 3-driven part of the peak current Io: 2A The logical part of the terminal supply area Vss: +5 V to +7 V (can board to take power +5 V) Logical part of the operating current range: 0 ~ 36mA Control signal input voltage range:    Low level:-0.3V ‰¤ Vin ‰¤ 1.5V    HIGH: 2.3V ‰¤ Vin ‰¤ Vss 7. Enable signal input voltage range:    Low level: -0.3 ‰¤ Vin ‰¤ 1.5V (control signal is invalid)    HIGH: 2.3V ‰¤ Vin ‰¤ Vss (control signal) Maximum power consumption: 20W (temperature T = 75 ° C) 9 Storage Temperature: -25 „ƒ ~ +130 „ƒ 10 Driver Board Size: 48mm * 43mm * 33mm (with fixed copper pillar and the heat sink height) 11 driver board Weight: 33g 12. Extension: control direction indicators, the logic part of the plate to take power interface. Instructions for use: Stepper motor driver: board of ENA and ENB is high here refers to the level of a TTL level. ENA for the A1 and A2 make terminal, ENB can end so as B1 and IB2. BJ public access stepper motor end.
