Leadshine compatible 3 Phase 3MD560 8.4A 1-axis Stepping Motor Driver

Leadshine 3-Phase Stepping Motor Driver.

High performance, low noise and low cost. Low driver heating and low motor heating. Supply voltage up to 50 V DC. Output peak current up to 8.4A (RMS6.0A)Input signal TTL compatible Automatic idle-current reduction Suitable for 3-phase stepping motors, including 3 lead and 6 lead motors Optically isolated differential input signals, pulse frequency up to 200 KHz, 8 selectable resolutions up to 10000 steps/revDIP switch current setting with 16 different values Over-voltage, short-voltage, over-current, and short-circuit protections Small size for easy mounting

Applications:Suitable for a wide range of 3-phase stepping motors from NEMA size 17 to 34. It can be used in various kinds of machines, such as X-Y tables, labeling machines, laser cutters, engraving machines, and pick-place devices, and etc. They are extremely suitable for the applications desired with low noise, low vibration, high speed and high precision.

Features:
* 20 to 50V DC Supply Voltage
* Ideal for 3-phase, 3 leads or 6 leads step motors
* Automatic idle-current reduction
* Frequency Input support up to 200KHz
* Up to 10,000 steps resolution

Specification:
* Current: Min 1.5A to 6A rms (2.1A ~ 8.4A peak)
* Voltage: Min 20V Typical: 36V Max: 50V DC
* Logic current: Min 7mA Typical: 10mA
* Input frequency: 0 to 200KHz
