Leadshine HBS86H 2-Phase Hybird servo Drive+86HS40-EC Stepper motor 4N.m


Description(HBS86H):
The HBS series offers an alternative for applications requiring high performance and high reliability when the servo was the only choice.
Includes a 2-phase stepper motor combined with fully digital, high performance drive and an internal encoder which is used to close the position.
Fast response, no hunting

Feature(HBS86H):
HBS86H 2-phase Hybrid Servo Drive
20-70VAC or 30-90VDC, 8.2A Peak
Closed-loop, eliminates loss of synchronization
Broader operating range-higher torque and higher speed
Do not need a high torque margin and No Tuning and always stable
Fast response, no delay and almost no settle time
High torque at starting and low speed, high stiffness at standstill and Lower cost

Description(86HS40-EC-1000):
1.Leadshine 86HS40-EC-1000 is a 2-phase NEMA 34 stepper motor with 4,000 CPR (1,000-line) incremental encoder (A , A-, B , B- signals). It is built with high quality material and can move smoothly with very low noise and heating.
2.When driven by Leadshineeasy servo drives (closed loop stepper drives), the position loop between 86HS40-EC and the drive is closed. You will never get stall or loss of steps, often seen in open loop stepper systems. Because there is no torque resolution needed like in open loop stepper systems, you can much better high-speed performance than open loop stepper systems by increasing up to 30%.
3.Leadshine 86HS40-EC can also driven by regular open loop 2-phase stepper drives and feedback encoder signals to motion controllers, or external devices.

Include:
1 x HBS86H servo Drive
1 x 86HS40-EC-1000 stepper motor
1 x 3m Encoder Cord
