Laguna Tools V-Way Slot Mortiser

The Platinum Series V-way Slot Mortiser allows users to easily and accurately cut slot mortises for a wide variety of projects. The 3-axis table raises and lowers on dovetail ways by an acme threaded rod for smooth operation. The table glides effortlessly on bearings in v-ways. The single handle operation allows for side to side and plunge movements with one hand. The double-boxed welded steel frame is very rigid and contains a storage compartment with door. Standard features include miter gauge, two position hold down clamp, dowel indexing accessory, hinged chuck guard, and reversible motor.
MM0200-0250

• Motor 3 HP - 220 volts - single phase
• Chuck capacity 5/8"
• Work table size 8" x 19.5"
• Side to side travel 11"
• Plunge travel 5.5"
• Table vertical travel 5.5"
• Maximum mortise height above table 9.5"
• Miter fence 18" x 2-1/4"
• Drill index centers 16, 20, 22, 25 mm
• Height to top of machine 42"
• Base size 20.5" x 27"
• Weight 270 lbs
