Keedox® CNC 3 Axis Electronic Wireless USB Handwheel Pulse Generator MPG Pendant for Mach 3 4Axis Engraving Machine Router (HandWheel-04)

Operating Instructions:
1. When Mach3 is installed , there will be a folder created named "PlugIns" in the Mach3 folder. This folder is the location to put and Plugin files that you want Mach3 to know about. Place"ShuttlePro.dll" in the \Mach3\PlugIns folder. Check and make sure it is there.
2．Setup diver for automatically set the knife height function.M930.m1s copy the installation directory to the MACH3 ..\Mach3\macros\Mach3Mill.
3. Now that the ShuttlePro.dll file is in \Mach3\PlugIns, the next step is to connect thehuttlePro. If you are certain that your ShuttlePro is working and your hardware is working then you can simply plug in the ShuttlePro to one of the USB ports.
4. Once the ShuttlePro is connected, start Mach3 and go to the "Config" menu choice and select "ConfigPlugins". You should see the ShuttlePro choice with a green checkmark in front of it. If it is not checked, you can check it. The checkmark means that Mach3 found the ShuttlePro on tartup. Click the "CONFIG" in yellow and set the buttons as you wish.
5. Once you have the proper button selected in the Mach3 ShuttlePro Plugin CONFIG menu, your Shuttle device should be working properly.

Package Include:
1xWireless USB Receiver
1xCNC Wireless Remote Handle
1xCD for Manual and mach3 software
