Intel Corp. - De3815tykh0e Kit Nuc "Product Category: Motherboards/Nuc Boards"

De3815tykh0e Kit Nuc

Boxed Next Unit of Computing Kit - Processor - Intel Atom Processor E3815 (1.46GHz Single Core 512KB Cache 5W TDP) Memory - DDR3L SODIMM - 1.35V 1333/1600 MHz (down clocked to 1066 MHz) 8GB maximum Graphics - Intel HD Graphics (up to 400MHz) - 1x HDMI 1.4a - 1x eDP 1.3 (2-lane with backlight and adjustable voltage/timings) - 1x VGA Audio - Multi-channel digital audio via HDMI interface - Back panel headphone/microphone jack Peripheral Connectivity - 1x USB 3.0 port on the front panel - 2x USB 2.0 ports on the back panel - 3x Internal USB 2.0 ports (2x5 + 1x5 headers) Storage - 4GB eMMC storage device built-in - Internal support for 2.5 HDD or SSD (up to 9.5mm thickness) Networking - 10/100/1000Mbps Network connection - Half-length PCIe* mini-card slot and wireless antennas pre-assembled (for wireless card support) Enclosure - Metallic gray plastic ring with black sides - Dimensions: 190mm x 116mm x 40mm Power Adapter - 12V 36W wall-mount AC-DC power adapter (12-19V DC back panel power connector) - Multi-country plugs (IEC types A/C/G/I) Additional Features - Fanless design - Discrete Trusted Platform Module (TPM 1.2) - Watchdog timer (hardwired to board reset) - Custom Solutions header (DMIC AppLaunch GPIO HDMI_CEC SMBus I2C[0:1] PWM[0:1] w/5V buffers 1.8/3.3/5 Vstby power) - 2x Serial ports header (TXD/RXD/RTS/CTS w/5V transceivers) - 12-24V DC internal power header - Compatible with WES 8 WES 7 Linux (Android support by Q2 14) - Vertical stand - VESA mount bracket (75x75mm and 100x100mm compatible) - Kensington lock support - 3-year Advanced Warranty Replacement - Thin Canyon "
