IPD Gage and Software

A versatile Measurement System for internal pitch Diameters, as well as internal bores, Grooves, recesses and internal gears. Major Features: Major breakthrough in utilizing computer Software With a Measuring instrument. With this new concept, accurate Measurements of internal Threads and compensation calculations for Ball Diameter variations or lead Angles are Made extremely simple. The Software diskettes supplied With the IPD Gage Can be used in any IBM compatible PC to obtain All data required for accurate inspection of any specific internal Thread Without the necessity of a master Gage. Easy to Set IPD Gage With Micrometer or Gage Blocks, etc. Universal, Can be used as general purpose internal Gage for Measuring bores, Grooves and pitch Diameters of Screw Threads and internal gears, etc. indicator alone, With the included Adapter, Extensions and contact Points, make it possible to Measure internal Threads and bores from 7+" to 18". Precision Made in U.S.A. Rigid construction Plus Special High Precision pivot bearings assure repeatability of .0002" or less. Balanced Body design for easy and convenient handling. Adjustable contact pressure. Carbide Ball contact Points are optional, Not included. System includes internal Gage, 1" Travel indicator, indicator-Adapter, 8 Extensions (1/4", 3/8", 1/2", 3/4", 1", 2", 3" and 4" Long), Measuring Tip organizer, 2 Standard contact Points 1/4" Long, Allen Wrench, fitted Case Plus Software casSette for internal pitch Diameter Threads and instruction manual. Specifications: Measuring Range: Bores- .93" to 8" Nominal Size Threads- 1 1/8" to 8" Extended Range With included indicator Adapter- 7 1/2" to 18" Gage Arm Travel - .625" Maximum reach in 1-1/4" Dia. bore- 4.8" 1" Travel indicator Graduation- .0005" The IPD Software complies With ANSI Standards; fully compensates for the effects of lead Angle. On screen explanation, No commands to remember. Error free data entry, will detect invalid input data.
