Huawei ME909u-521 4G/LTE- 3G/HSPA+ DC LGA Mini-PCIe Express Wifi Router Module

Huawei ME909u-521 4G/LTE- 3G/HSPA+ DC LGA Mini-PCIe Express Wifi Router Module



Feature:
Huawei ME909u-521 4G/LTE- 3G/HSPA+ DC LGA Module
ME909u-521(B1/B2/B3/B5/B7/B8/B20), for European market.
ME909u-523(B2/B4/B5/B13/B17/B25/B26), for North America market.
ME909u-XXX (TBD), for Japan market.

ME909 family is high-quality designed LTE module in small size and Huawei standard LGA form factor which specially for industrial-grade M2M applications such as vehicle telematics, tracking, mobile payment, industrial router, safety monitor and industrial PDAs.
The ME909 family support 100Mbps downlink data rate, include enhanced features like FOTA, USSD, IPV6/IPV4 and Huawei enhanced AT commands.

Form Factor: 145-pin LGA

Bands
ME909u-521 variant:
LTE (FDD) B1/B2/B3/B5/B7/B8/B20
DC-HSPA+/HSPA+/HSPA/UMTS dual-band B1/B2/B5/B8
EDGE/ GPRS/ GSM quad-band 850/900/1800/1900 MHz

Data Transfer Rate:
DC-HSPA+ :Downlink:42 Mbps, Uplink: 5.76 Mbps
LTE FDD: Downlink:100 Mbps, Uplink: 50 Mbps @Bandwidth 20M (CAT3)

Interface
Antenna interface
UART
USB 2.0 High speed
PCM Voice
SIM Card
Multiple GPIOs
Power supply
Reset
Power_On off
SDIO
HSIC
I2C
SPI

Power Supply: 3.2 V to 4.2 V (typical: 3.8 V)
Voice: PCM Voice
Temp Range: -30°C to 75°C

GPS/Glonass:
GPS Standalone
A-GPS

Special Features:
FOTA
USSD
IPV6/IPV4

Operating System: Linux, Android

Approvals:
CE
GCF
RoHS Compliant
