HiFimeDIY SABRE DAC 2, UAE23+ Asynchronous USB DAC with headphone amplifier and built in USB isolator

This Sabre DAC features an USB Isolator chip (adum4160) that isolates the DAC from USB power. It can then be supplied with an external clean power supply. It accepts a wide range of DC and AC voltages. Batteries can also be used for optimal performance. This makes it slightly less portable than the smaller brother, theUSB powered Sabre DAC, but might offer even better performance! On this new batch we have added a headphone amp to this dac. This output is 3.5mm on the front and volume through this output is adjustable with an analog volume pot. The headphone output can drive headphones down to 16ohm. There is also a direct line out from the ES9023 chip (RCA plugs on the back). This output can also be used to drive many headphones (with a RCA to 3.5mm jack adaptor). You can experiment to see which you prefer for your headphones. It can also b used as an USB to Coaxial adapter. The coax besides the USB input is output! Features: - USB input. (the COAX connector is output! - don't buy this if you need coax input) - Two outputs: 3.5m (headphone amplified) and RCA (line level) - Analog volume control (headphone output only!) - Headphone output based on TPA6138 driver - No drivers required for Mac, Windows and Linux! - Requires external power supply (not included): DC between 5-15V or AC 4-11V. 500mA. Both polarity DC is ok. Plug is 5.5-6/2.1. From 5.5mm to 6mm on outside and 2.1mm in the middle. - Power draw: 53mA (63mA with TCXO) when playback. and 2mA at USB Bus. 18mA when USB cable is unplugged. - Quality 30cm USB cable included
