Heck Industries 4000 Bevel-Mill Plate Beveler, 3/4" Maximum Bevel, 2HP, 110V

The Heck Industries 4000 Bevel-Mill Plate Beveler is an electrically powered handheld machine that provides a 3/4" maximum burr-free bevel on most materials with a minimum thickness of 1/8", and is made in the USA. The 2 hp, 110V motor enables beveling at approximately 3 feet per minute on mild steel without creating dust, fumes, or heat. It is powered using the included 6-ft. cord with a 3-prong plug. The machine's depth of cut can be adjusted and the bevel angle can be set between 15 and 45 degrees to create a customized bevel. The attached V-block plate supports the machine on the workpiece, reducing operator strain. The beveler includes 10 square, C-5 grade carbide inserts that can each be indexed 4 times to refresh the cutter.

Specifications
Bevel angle15 to 45 degrees
Maximum bevel3/4"
Minimum bevel0"
Minimum workpiece thickness1/8"
V-block length8"
Power2 hp, 110 volts
Weight22 lb.

Power milling machines have rotating cutters that remove material from a workpiece surface. Milling machines come in contact with the workpiece horizontally, vertically, or in both directions.

Heck Industries manufactures metal working machinery, including plate beveling machines, bench models, and power feed machines. The company, founded in 1966, is headquartered in Hartland, MI.

What's in the Box?

  • Heck Industries 4000 Beveler
  • 10 indexable inserts

  • TitleHeck Industries 4000 Bevel-Mill Plate Beveler, 3/4" Maximum Bevel, 2HP, 110V
  • BrandHeck
  • ManufacturerHeck Industries
  • BindingMisc.
  • ProductGroupBISS
  • ItemPartNumber4000
  • Model4000
  • ReleaseDate2017-11-25T00:00:01Z
  • UnitCount1
  • EANs7430988210901
