Happy Hours® 1080P 720P Mini SD-SDI HD-SDI 3G-SDI To HDMI Video Audio Converter HD TV Camera + US Plug Power Supply

Introduction

The MINI SDI to HDMI converter allows SD-SDI, HD-SDI and 3G-SDI signals to be shown on HDMI/SDI displays while ensuring high bit rates of

2.970 Gbit/s to give you fast signal transmission without any loss. For professionals this means that it is now easier to distribute and

extend your 3G SDI signal while giving you the ability to display your work on HDMI displays thanks to the built in HDMI converter.


Package:

1x 3G SDI to HDMI Converter

1x US Power Supply Adaptor

1x Operation Manual


Features

1.Operation at 2.970Gbit/s, 2.970/1.001Gbit/s, 1.485Gbit/s, 1.485/1.001Gbit/s and 270Mbits/s

2.Supports SMPTE 425M (Level A and Level B), SMPTE 424M, SMPTE 292M, SMPTE 259M-C

3.Equalized and re-clocked loop output? Integrated audio de-embedder for a maximum of 8 channel, 48 kHz audio

4.Conversion from SMPTE 425M level B to Level A 1080p 50/59.94/60 4:2:2 10-bit

5.Connect with other units to extend your signal over long distances


Specificaitons

1.Input Port:1 x BNC (SDI/HD-SDI/3G-SDI)

2.Output Port:1 x HDMI

3.SMPTE Standard:425M Level A & B, 424M, 292M, 259M-C

4.SDI Transmission Rates: 2.970 Gbit/s and 2.970/1.001 Gbit/s

5.In/Output Resolution:480i, 576i, 720p~50/59.94,60 ,1080i~50/59.94/60 ,1080p~23.98/24/25/29.97/30/50/59.94/60 ,

1080PsF~23.98/24/25/29.97/30
