Hantek MSO5062D 60MHz 2 CH 1GSa/s Oscilloscope 16CH Logic Analyzer 2 in 1

*Bandwidth:60MHz
*Sampling Rate:Max 1GS/s
*Memory Depth(Sample Points):Single-channel max 1M,Dual max 512K(4/16/40K optional)
*SEC/DIV Range:8ns-40s/div(stepping in a sequence:2,4,8)
*Sampling Rate/Delay Time Accuracy:+/-50ppm in any>=1ms time intervals
*Delta Time Measurement Accuracy(full bandwidth)
Single,"sampling"mode
+/-(1 sampling interval+100ppm x readings+0.6ns)
>16 times above average
+/-(1 samplinginterval+100ppm*readings+0.4 ns)
Sampling interval=SEC/DIV/200

Oscilloscope

Vertical,Trigger,Acquisition,Input,Measurement

*Logic Analyzer:

Sampled Channels:16(divided into 2 groups)
Max. Input Impedance:200K(C=10p)
Input Voltage Range -60~+60V
Logic Threshold Range -8~+8V
Max. Sample Rate 500MHz
Compatible Input TTL,CMOS,ECL
Sample Depth 512KSample
Cursors:The difference between voltage cursors deltaV.The difference between time cursors deltaT.1/deltaT calculated by Hz.
Measurement:Period and Frequency
Record Position:RefA,RefB

Trigger:

Edge:D0-D15 select slope(rising/falling edge)
Pulse Width:D0-D15 select pulse polarity (positive or negative pulse),trigger when(=,not=,>,<) trigger pulse width Code-type:D0-D15 select code-type(H,L,X)
Duration:D0-D15 select persist time and trigger when (data terminate/start/delay)
Queue:D0-D15 select specific data index(0-3) and code-type(H,L,X)
Repeat:D0-D15 select code-type(H,L,X) and repeat times
*General
Power Supply:100-240V
Probe Compensator Output:Output Voltage (typical),About 5Vpp input>=1M ohm load,1KHz Freq.
More details please visit Hantek web
