Hantek® 1008C Digital Oscilloscope DAQ 8CH Programmable Generator 2.4MSa/s 12Bits Auto Ignition Probe
Specificaiton:
Model: Hantek1008C
Vertical
Analog Channel: 8
Input Impedance: Resistance: 1M¦¸
Input Sensitivity: 10mV/div to 5V/div
Input Coupling: DC
Resolution: 12 bits
Horizontal
Memory Depth: 4K
Max. Input: 400V (DC+AC Peak)
Real-Time Sampling Rate: 2.4MSa/s
Time Base Range: 1ns/div to 20000s/div(1-2-5 sequences)
Time Base Precision: ¡À50ppm
Trigger
Source: CH1, CH2,CH3,CH4, CH5, CH6,CH7,CH8
Mode: Edge
X-Y Mode
X-Axis Input: CH1
Y-Axis Input: CH2
Cursors and Measurement
Voltage Measurement: Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase,Vavg, Vrms, Vcrms, Preshoot, Overshoot
Time Measurement: Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle
Cursors Measurement: Horizontal ,Vertical, Track, Auto Measure Modes
Waveform Signal Process: +,- , x,¡Â, FFT, Invert
Voltage Range:
10mV to 5V/div @ x 1 probe
100mV to 50V/div @ x 10 probe
10V to 5000V/div @ x 1000 probe
100V to 50000V/div @ x 10000 probe
200mV to 100V/div @ 20:1
Current Range :
100mA to 50.0A/div @ CC65(20A)
1000mA to 500.0A/div @ CC65(65A)
1A to 100.0A/div @ CC650(60A)
10A to 1000.0A/div @ CC650(650A)
1A to 200.0A/div @CC1100(100A)
10A to 2000.0A/div @CC1100(1100A)
Cursor: Time/frequency difference, voltage difference
FFT: Rectangular, Hanning, Hamming, Blackman Window
Math: Addition, subtraction, multiplication, division
Note:
Software support: Windows NT, Window 2000, Windows XP, VISTA, Windows 7
Package Included:
1 x 1008C DAQ oscilloscope
1 x Auto-probe
4 x Crocodile probes/cable
4 x BNC Connectors
1 x USB Cable
1 x CD (driver etc.) 1 x Auto-probe instruction
