HD900/5 JL Audio 5 Channel 900 Watt HD series Amplifier
5-channel amplifer
100 watts RMS x 4 at 4 ohms + 500 watts RMS x 1 (at 1.5-4 ohms)
75 watts RMS x 4 (at 1.5-3 ohms) + 500 watts RMS x 1 (at 1.5-4 ohms)
150 watts RMS x 2 bridged (at 3-6 ohms) + 500 watts RMS x 1 at (1.5-4 ohms)
variable high-pass filter on front and rear channels (50-500 Hz, 12 or 24dB/octave)
variable low-pass filter on subwoofer channel (50-500 Hz, 12 or 24dB/octave)
subsonic filter on sub channel (24 dB/oct at 30 Hz)
removable power and speaker plugs
optional wire remote for level control
Class D amplifier design
MOSFET power and output stages
differential-balanced inputs eliminate noise from your vehicle's electrical system
speaker- and preamp-level inputs (speaker-level input requires an otional adapter)
preamp outputs
4-gauge power and ground leads and a 60-amp fuse recommended - wiring and hardware not included with amplifier
no onboard fuses - when installing multiple amps in a system, an additional 60-amp in-line fuse between the distribution block and the amplifier is recommended
10-3/4"W x 1-15/16"H x 8-5/16"D
